Zig Zag Feeder

DETAIL INFORMATION

About Zig Zag Feeder:

1.Zig Zag Feeder Introduction:

1. Our Zig Zag Feeder speed can reach 0-20 m/min.  Precision is better than +/-0.05 mm. And suitable all kinds of metal coil.

2. Our Zig Zag Feeder is suitable 0.1-2.0 mm thickness all metal coil feeding.

3. Our Zig Zag Feeder widely used to computer, mobile phone,automobile industry,appliances manufacturing,

    medical apparatus and instruments, hardware & Metal parts etc industry.

2 .Zig Zag Feeder Feature And Advantage:

1. High precision:+/-0.05 mm

2. Suitable for material thickness :0.1-2.0 mm.

3.Suitable for all kinds of metal coil automatic feeding,easy to operate.

4.Suitable for metal parts, electron, electrical appliance, toy and auto parts continuous pressing production, straightening and      feeding.

5. Japan servo motor , PLC and other electrical parts,with little malfunction and long using time.High quality ,lowest maintenance.

6. Easy operation, safe and high stability.

7. We can customize the machine.

8.Fast speed: 20 m/min.

9. Save time ,save coil.

3.Zig Zag Feeder Main Parts Brand:

Motor	YASKAWA
PLC	DELTA
Man-machine interface	Weinview
Driver	YASKAWA
CE Certificate	Passed
Feeding way	Automatic
Feeding control way	Servo motor with PLC
Bearing	Japan NSK
Air cylinder	Japan CKD
Big customer	Media, Haier , AUDI, DONGFENG etc.

3.Zig Zag Feeder Technology Data:

Name

Zig Zag Feeder

Model

NCP-200

NCP-300

NCP-400

NCP-500

NCP-600

NCP-700

NCP-800

NCP-900

NCP-1000

Coil width

mm

200

300

400

500

600

700

800

900

1000

Coil thickness

mm

0.1-2.0

Max. Feeding length

mm

0-9999.99

Migration speed

m/min

30（max）

Feeding speed

m/min

20（max）

Migration distance

(max）mm

100

150

200

250

300

350

400

450

500

Pressing way

Spring Type

Releasing System

Pneumatic Type

Feed Precision

mm

±0.2

Feeding Direction

Left→Right

Applicable Material

SPCC、SUS

Drive system

Single geared

Double Geared

Control way

Electric control cabinet and hand switch box

Feeding line height

mm

Distance from floor to press worktable + Bottom mould height ±100mm

4.Our Zig Zag Feeder In Our Our Factory,Have Exported To India:

5.Zig Zag Feeder Producing Line:

About Hong-Er Machine:

1.  Hong-Er Machine Introduction

Shenzhen Honger Machine Equipment Co.,Ltd are professional Zig Zag Feeder,2 In 1 Sheet Steel

Straightener And Uncoiler, Decoiler Straightener Feeder,Sheet Metal Press Machine,Punching Press Machine,Decoiling

and Straightening Machine,NC Servo Roll Feeder,Servo Roll Feeder,Zig Zag Feeder,Mechanical Feeder,

Rapid Air Feeder,Uncoiler Machine,Sheet Metal Decoiler,Strip Straightening Machine,Sheet

Straightening Machine Manufacturer/Factory/Supplier/Exporter in Guangdong of China.

We are the only own international advanced big CNC that include FPW & VMC.

The Top one quality best price Machine manufacturer in Guangdong.

We are near to Hongkong,Guanggou,Dongguan etc. And Shenzhen Baoan Airport is

international airport,If you want to visit us ,that is very convenient.

Welcome to visit our factory!

2.Hong-Er Machine CE Certificate:

3.Hong-Er Factory And Workshop:

About Hong-Er Service:

1. We Can Provide To Buyer Details Requirement:

Package	Wooden case and film package
After-Sale service	1 Year
Delivery time	0-20 workdays
Shipping way	Ocean shipping
Payment term	T/T  L/C  Cash or other



2.Zig Zag Feeder Packing:wooden case or other package. According to the actual condition.

Contact:

Email: cherry@he-machine.com

Tel: +86 15014793070
